Энкодер безопасности SICK DFS60S-BAOK01024, артикул 1083278

Энкодер безопасности SICK DFS60S-BAOK01024, артикул 1083278.

Напряжение питания: 4.5 ... 32 V. Выходной сигнал: Sin/Cos. Интерфейс связи: Incremental. Подключение: Cable, 8-wire, universal, 1.5 m 1) [примечание 1]. Диаметр вала: 6 mm With feather key.

Семейство: DFS60S Pro. При подборе сверяйте артикул 1083278 и полное обозначение DFS60S-BAOK01024.

Примечания к параметрам (EN)

1. 1) The universal cable connection is positioned so that it can be laid in a radial or axial direction without any kinks. UL approval not available. 2) Short-circuit to another channel or GND permitted for max. 30 s. In the case of U S ≤ 12 V additional short-circuit to U S permitted for max. 30 s.

2. 1) With plug and mating plug fitted minimum IP65. 2) Allow for self-heating of approx. 3.0 K per 1,000 rpm regarding the permissible operating temperature. 3) Checked to operation with vector length monitoring.

3. 1) Based on encoder with male connector. 2) Allow for self-heating of approx. 3.0 K per 1,000 rpm regarding the permissible operating temperature. 3) On maximum operating speed and temperature.
